CAUTION:
To ensure proper thermal cooling, the four server tray slots must be populated with server nodes or
node blanks.

Rack warnings

WARNING:
To reduce the risk of personal injury or damage to the equipment, be sure that:
• The leveling jacks are extended to the floor.
• The full weight of the rack rests on the leveling jacks.
• The stabilizing feet are attached to the rack if it is a single-rack installation.
• The racks are coupled together in multiple-rack installations.
• Only one component is extended at a time. A rack may become unstable if more than one
component is extended for any reason.
WARNING:
To reduce the risk of personal injury or equipment damage when unloading a rack:
• At least two people are needed to safely unload the rack from the pallet. An empty 42U rack can
weigh as much as 115 kg (253 lb), can stand more than 2.1 m (7 ft) tall, and might become unstable
when being moved on its casters.
• Never stand in front of the rack when it is rolling down the ramp from the pallet. Always handle the
rack from both sides.
WARNING:
To reduce the risk of personal injury or damage to the equipment, adequately stabilize the rack before
extending a component outside the rack. Extend only one component at a time. A rack may become
unstable if more than one component is extended.
WARNING:
When installing a server in a telco rack, be sure that the rack frame is adequately secured at the top and
bottom to the building structure.

Preparation procedures

To access some components and perform certain service procedures, you must perform one or more of the
following procedures:
• Power down the system.
• Power down the node .
• Remove the node from the chassis.
• Remove the node blank from the chassis.
• Remove the power supply.
• Remove the chassis from the rack.
• Remove the security bezel.
• Remove the PDB cover.
• Remove the access panel.
• Remove the fan cages.
• Remove the chassis PDB assembly.
• Remove the rear I/O blank.
• Remove the air baffle.
Rack warnings 31
