• NVIDIA Quadro K4200 GPU or NVIDIA Quadro M4000 GPU

Remove Accelerator 1 from the three-slot riser cage assembly

About this task
To remove the component:
Procedure
1. Power down the node .
2. Disconnect all peripheral cables from the node .
3. Remove the node from the chassis .
4. Place the node on a flat, level surface.
5. Remove the three-slot PCI riser cage assembly.
6. Disconnect the accelerator power cable from the bayonet board.
7. Remove the riser cage bracket from the three-slot riser cage assembly.
8. Disconnect all cables from the accelerators.
9. Remove Accelerator 2 from the three-slot riser cage assembly.
10. Remove Accelerator 1 from the three-slot riser cage assembly.
Remove Accelerator 1 from the three-slot riser cage assembly 55
