Replacing Accelerator 1 In The Flexiblelom 2U Node Riser Cage Assembly - HP Apollo 2000 System Maintenance And Service Manual

Three-slot GPU-direct PCI riser cage assembly (PN 798188-B21)
Dual accelerator options
• Intel Xeon Phi Coprocessor
1
5110P
• AMD FirePro S9150 GPU
• NVIDIA Tesla K40 GPU
Accelerator
• NVIDIA GRID K2 Reverse Air
Flow GPU Accelerator
• NVIDIA Tesla P40 GPU
Accelerator
1
Dual accelerator configurations only. If installing this accelerator model, populate both slot 3 and slot 4 with
accelerators to ensure proper thermal cooling.
2
The riser cage supports both single and dual accelerator configurations for this accelerator model. If
installing a single accelerator, install it into slot 3 and leave slot 4 empty.
Three-slot Enhanced GPU-direct PCI riser cage assembly (PN 852769-B21)
Dual accelerator options
• AMD FirePro S9150 GPU
1
Dual accelerator configurations only. If installing this accelerator model, populate both slot 3 and slot 4 with
accelerators to ensure proper thermal cooling.
Three-slot GPU-direct with re-timer PCI riser cage assembly (PN 827353-B21)
Dual accelerator options
• AMD FirePro S7150 GPU
• NVIDIA Tesla K80 GPU
Accelerator
• NVIDIA Tesla M60 GPU
Accelerator
• NVIDIA Tesla M40 GPU
Accelerator
• NVIDIA Tesla P100 GPU
Accelerator
1
Dual accelerator configurations only. If installing this accelerator model, populate both slot 3 and slot 4 with
accelerators to ensure proper thermal cooling.
2
The riser cage supports both single and dual accelerator configurations for this accelerator model. If
installing a single accelerator, install it into slot 3 and leave slot 4 empty.
For more information, see "Accelerator cabling."

Replacing Accelerator 1 in the FlexibleLOM 2U node riser cage assembly

About this task
To remove the component:
Power cable
Both 825634-001 and 825635-001
are required
1
1
Both 825634-001 and 825635-001
are required
2
Both 826636-001 and 825637-001
are required
2
Power cable
Both 825634-001 and 825635-001
1
are required
Power cable
Both 825634-001 and 825635-001
1
are required
Both 825636-001 and 825637-001
are required
2
2
2
2
Replacing Accelerator 1 in the FlexibleLOM 2U node riser cage assembly
2-pin adapter cables
Not supported
805206-001 required for each
accelerator
Not supported
2-pin adapter cables
Not supported
2-pin adapter cables
Not supported
Not supported
99
