Remove the chassis access panel

Procedure
1. Power down all nodes.
2. Disconnect all peripheral cables from the nodes and chassis.
WARNING:
The chassis is very heavy. To reduce the risk of personal injury or damage to the equipment:
• Observe local occupational health and safety requirements and guidelines for manual material
handling.
• Remove all installed components from the chassis before installing or moving the chassis.
• Use caution and get help to lift and stabilize the chassis during installation or removal, especially
when the chassis is not fastened to the rack.
CAUTION:
Before installing the chassis into the rack or removing the chassis from the rack, Hewlett Packard
Enterprise recommends removing the nodes, the drives, and the power supplies. Because a fully
populated chassis is heavy, removing these components facilitates moving the chassis.
3. Remove all nodes from the chassis.
4. If installed, remove the security bezel.
5. Remove all drives.
6. If installed, remove the RCM module.
7. Remove all power supplies.
8. Remove the chassis from the rack.
9. Unlock the access panel latch using the T-15 Torx screwdriver and release the access panel latch.
10. Slide the access panel back about 1.5 cm (0.5 in).
11. Lift and remove the access panel.

Remove the fan cages

1. Power down the system.
2. Disconnect all peripheral cables from the nodes and chassis.
3. Remove all nodes from the chassis.
