Hach sc200 User Manual page 150

Maximum Current
Consumption
NOTE 1. Outputs #1, #2, #3, and #4 share a common signal.
All other outputs have individual contacts.
TRANSISTOR Number of Outputs
OUTPUTS
Output Type
Galvanic Isolation
Output Current
Maximum Frequency
ON Voltage Drop
Short Circuit Protection
Power Supply
Operating Voltage
Power Supply
Nominal Operating Voltage 24 VDC
npn (sink) Power Supply
Operating Voltage
ENVIRON Operating Temperature
MENTAL
Storage Temperature
Relative Humidity (RH)
Dimensions
Weight
4-10
90 mA @ 24 VDC
4; each can be individually wired
as pnp (source) or npn (sink)
pnp P-MOSFET (open drain)
npn open collector
Yes
pnp 0.5 Amp max (per output)
Total current: 2 A max (per group)
npn 50 mA max (per output)
Total current: 150 mA (per group)
Resistive Load 20 Hz
Inductive Load 0.5 Hz
pnp 0.5 VDC max
npn 0.85 VDC max
Yes (pnp only)
20.4 to 28.8 VDC
3.5 V to 28.8 VDC (unrelated to Remote
Relay Module voltage or Controller voltage)
0 to 50°C (32 to 122°F) -
-20 to 60°C (-4to 140°F)
5% to 95% (non-condensing)
138 W x 23 H x 123 mm D
(5.43 W x 0.9 H x 4.84" D)
222 g (7.8 oz)
