Audio status

xStatus Audio
Shows the top level overview of the audio status. The identities of the LocalInput, RemoteInput,
LocalOutput and RemoteOutput are used when querying additional information.
xStatus Audio Microphones Mute
Shows the microphones mute mode.
Value space of the result returned:
<On/Off>
Example:
xStatus Audio Microphones Mute
*s Audio Microphones Mute: Off
** end
xStatus Audio Volume
Shows the volume level (dB) of the loudspeaker output.
Value space of the result returned:
<0..100>
Example:
xStatus Audio Volume
*s Audio Volume: 70
** end
xStatus Audio VolumeMute
Shows whether the endpoint volume is set to mute.
Value space of the result returned:
<Off/On>
Example:
xStatus Audio VolumeMute
*s Audio VolumeMute: Off
** end
SX20 Codec API Reference Guide TC7.3, OCTOBER 2015.
D14949.13
About the API xConfiguration
xStatus Audio Input RemoteInput [n] CallId
xStatus Audio Input Connectors Microphone [n] ConnectionStatus
xStatus Audio Input Connectors Microphone [n] EcReferenceDelay
137
xCommand
Shows the CallId for the remote audio input.
You can run the command xStatus Audio Input RemoteInput to find the identity [n] of the input.
Value space of the result returned:
<0..65534>
Example:
xStatus Audio Input RemoteInput 8 CallId
*s Audio Input RemoteInput 8 CallId: 28
** end
Indicates whether a microphone is detected on the microphone input connector.
Value space of the result returned:
<NotConnected/HeadsetMicConnected/GenesisConnected/Connected>
Example:
xStatus Audio Input Connectors Microphone ConnectionStatus
*s Audio Input Connectors Microphone 1 ConnectionStatus: NotConnected
*s Audio Input Connectors Microphone 2 ConnectionStatus: Connected
** end
Returns the detected latency for each loudspeaker to microphone path. The result is in milliseconds.
Value space of the result returned:
<Integer>
Example:
xStatus Audio Input Connectors Microphone 1 EcReferenceDelay
*s Audio Connectors Microphone 1 EcReferenceDelay: 120
** end
