xCommand Conference DoNotDisturb Deactivate
This command switches off the Do Not Disturb mode. This command only takes effect when
xConfiguration Conference DoNotDisturb Mode is set to Timed. When Do Not Disturb is switched
off incoming calls come through as normal.
Requires user role: USER
Example:
xCommand Conference DoNotDisturb Deactivate
SX20 Codec API Reference Guide TC7.3, OCTOBER 2015.
D14949.13
About the API xConfiguration
Dial commands
xCommand Dial
101
xCommand xCommand
Dial out from the system. Returns information about the CallId and ConferenceId, which are required
for some other commands.
Number: Enter the number or address.
Protocol: Select the Auto, SIP, H323 or H320 protocol.
CallRate: Set a call rate.
CallType: Select the audio or video call type.
BookingId: Any identifier that an external booking system (e.g. TMS, CTS-MAN) can use for its own
references to match placed calls with the booking systems internal identifier for a meeting. This can
be any string, e.g. a GUID. The booking Id is supplied in call logs, call events etc for the call.
DisplayName: The display name of the remote participant.
Requires user role: USER
Parameters:
Number(r): <S: 0, 255>
Protocol: <H320/H323/Sip>
CallRate: <64..6000>
CallType: <Audio/Video>
BookingId: <S: 0, 255>
Appearance: <1..999999999>
DisplayName: <S: 0, 255>
Example:
xCommand Dial Number:543210 Protocol:h323
