xConfiguration Conference [1..1] Presentation OnPlacedOnHold
Define whether or not to continue sharing a presentation after the remote site has put you on hold.
Requires user role: ADMIN
Value space: <Stop/NoAction>
Stop: The video system stops the presentation sharing when the remote site puts you on hold. The
presentation will not continue when the call is resumed.
NoAction: The video system will not stop the presentation sharing when put on hold. The
presentation will not be shared while you are on hold, but it will continue automatically when the
call is resumed.
Example: xConfiguration Conference 1 Presentation OnPlacedOnHold: NoAction
xConfiguration Conference [1..1] Multipoint Mode
Define how the video system handles multiparty video conferences.
If registered to a Cisco TelePresence Video Communication Server (VCS), the video system can
either use its own built-in MultiSite feature, or it can rely on the MultiWay network solution. MultiWay
requires that the video network includes a multipoint control unit (MCU).
If registered to a Cisco Unified Communications Manager (CUCM) version 8.6.2 or newer, the video
system can use either the CUCM conference bridge, or the video system's own built-in MultiSite
feature. Which one to use is set-up by CUCM.
Both MultiWay and the CUCM conference bridge allows you to set up conferences with many
participants. The built-in MultiSite allows up to four participants (yourself included).
Note that the built-in MultiSite is optional and may not be available on all video systems.
Requires user role: ADMIN
Value space: <Auto/Off/MultiSite/MultiWay/CUCMMediaResourceGroupList>
Auto: The multipoint method available will be choosen automatically; if none are available the
Multipoint Mode will automatically be set to Off. If both MultiWay and MultiSite are available, the
MultiWay service takes priority over the built-in MultiSite.
Off: Multiparty conferences are not allowed.
MultiSite: Multiparty conferences are set up using the built-in MultiSite feature. If MultiSite is
chosen when the MultiSite feature is not available, the Multipoint Mode will automatically be set to
Off.
MultiWay: Multiparty conferences are set up using the MultiWay service. If MultiWay is chosen
when the MultiWay service is not available, the Multipoint Mode will automatically be set to Off.
This may occur when the NetworkServices MultiWay Address setting is empty or not properly set.
CUCMMediaResourceGroupList: Multiparty conferences (ad hoc conferences) are hosted by
the CUCM configured conference bridge. This setting is provisioned by CUCM in a CUCM
environment and should never be set manually by the user.
Example: xConfiguration Conference 1 Multipoint Mode: Auto
SX20 Codec API Reference Guide TC7.3, OCTOBER 2015.
D14949.13
About the API xConfiguration xConfiguration
xConfiguration Conference [1..1] IncomingMultisiteCall Mode
40
xCommand
Select whether or not to allow incoming calls when already in a call/conference.
Requires user role: ADMIN
Value space: <Allow/Deny>
Allow: You will be notified when someone calls you while you are already in a call. You can accept
the incoming call or not. The ongoing call may be put on hold while answering the incoming call; or
you may merge the calls (requires MultiSite or MultiWay support).
Deny: An incoming call will be rejected if you are already in a call. You will not be notified about the
incoming call. However, the call will appear as a missed call in the call history list.
Example: xConfiguration Conference 1 IncomingMultisiteCall Mode: Allow
