xConfiguration NetworkServices NTP Address
The address of the NTP server that will be used when NetworkServices NTP Mode is set to Manual,
and when NetworkServices NTP Mode is set to Auto and no address is supplied by a DHCP server.
Requires user role: ADMIN
Value space: <S: 0, 64>
Format: A valid IPv4 address, IPv6 address or DNS name.
Example: xConfiguration NetworkServices NTP Address: "0.tandberg.pool.ntp.org"
xConfiguration NetworkServices SNMP Mode
SNMP (Simple Network Management Protocol) is used in network management systems to monitor
network-attached devices (routers, servers, switches, projectors, etc) for conditions that warrant
administrative attention. SNMP exposes management data in the form of variables on the managed
systems, which describe the system configuration. These variables can then be queried (set to
ReadOnly) and sometimes set (set to ReadWrite) by managing applications.
Requires user role: ADMIN
Value space: <Off/ReadOnly/ReadWrite>
Off: Disable the SNMP network service.
ReadOnly: Enable the SNMP network service for queries only.
ReadWrite: Enable the SNMP network service for both queries and commands.
Example: xConfiguration NetworkServices SNMP Mode: ReadOnly
xConfiguration NetworkServices SNMP Host [1..3] Address
Enter the address of up to three SNMP Managers.
The system's SNMP Agent (in the codec) responds to requests from SNMP Managers (a PC
program etc.), for example about system location and system contact. SNMP traps are not
supported.
Requires user role: ADMIN
Value space: <S: 0, 64>
Format: A valid IPv4 address, IPv6 address or DNS name.
Example: xConfiguration NetworkServices SNMP Host 1 Address: ""
SX20 Codec API Reference Guide TC7.3, OCTOBER 2015.
D14949.13
About the API xConfiguration xConfiguration
xConfiguration NetworkServices SNMP CommunityName
xConfiguration NetworkServices SNMP SystemContact
xConfiguration NetworkServices SNMP SystemLocation
xConfiguration NetworkServices SSH Mode
54
xCommand
Enter the name of the Network Services SNMP Community. SNMP Community names are used
to authenticate SNMP requests. SNMP requests must have a password (case sensitive) in order
to receive a response from the SNMP Agent in the codec. The default password is "public". If
you have the Cisco TelePresence Management Suite (TMS) you must make sure the same SNMP
Community is configured there too. NOTE: The SNMP Community password is case sensitive.
Requires user role: ADMIN
Value space: <S: 0, 50>
Format: String with a maximum of 50 characters.
Example: xConfiguration NetworkServices SNMP CommunityName: "public"
Enter the name of the Network Services SNMP System Contact.
Requires user role: ADMIN
Value space: <S: 0, 50>
Format: String with a maximum of 50 characters.
Example: xConfiguration NetworkServices SNMP SystemContact: ""
Enter the name of the Network Services SNMP System Location.
Requires user role: ADMIN
Value space: <S: 0, 50>
Format: String with a maximum of 50 characters.
Example: xConfiguration NetworkServices SNMP SystemLocation: ""
SSH (or Secure Shell) protocol can provide secure encrypted communication between the codec
and your local computer.
Requires user role: ADMIN
Value space: <Off/On>
Off: The SSH protocol is disabled.
On: The SSH protocol is enabled.
Example: xConfiguration NetworkServices SSH Mode: On
