Description of the xStatus commands
The following pages will list an example of the xStatus commands and the response. Status
type commands returns information about the system and system processes. You can query all
information or just some of it.
We recommend you visit our web site regularly for updated versions of the manual.
Go to: http://www.cisco.com/go/telepresence/docs
D14641.06 Codec C90 API Reference Guide TC5.0 November 2011.
© 2010-2011 Cisco Systems, Inc. All rights reserved.
About the API xConfiguration

The Audio status

xStatus Audio

113
xCommand
Shows the top level overview of the audio status. The identities of the LocalInput, RemoteInput,
LocalOutput and RemoteOutput are used when querying additional information.
Example:
xStatus Audio
*s Audio Microphones Mute: Off
*s Audio Volume: 60
*s Audio Input LocalInput 1 Name: "Microphone"
*s Audio Input LocalInput 1 MixerMode: "GainShared"
*s Audio Input LocalInput 1 Mute: "Off"
*s Audio Input LocalInput 1 Channels: 1
*s Audio Input LocalInput 1 AGC: "On"
*s Audio Input LocalInput 1 Connector: "Microphone.1"
*s Audio Input LocalInput 1 Connector: "Microphone.2"
*s Audio Input LocalInput 1 Connector: "Microphone.3"
*s Audio Input LocalInput 1 Connector: "Microphone.4"
*s Audio Input LocalInput 1 Connector: "Microphone.5"
*s Audio Input LocalInput 1 Connector: "Microphone.6"
*s Audio Input LocalInput 1 Connector: "Microphone.7"
*s Audio Input LocalInput 1 Connector: "Microphone.8"
*s Audio Input LocalInput 2 Name: "PC input"
*s Audio Input LocalInput 2 MixerMode: "Fixed"
*s Audio Input LocalInput 2 Mute: "Off"
*s Audio Input LocalInput 2 Channels: 2
*s Audio Input LocalInput 2 AGC: "Off"
*s Audio Input LocalInput 2 Connector: "Line.1"
*s Audio Input LocalInput 2 Connector: "Line.2"
*s Audio Input LocalInput 3 Name: "DVD input"
*s Audio Input LocalInput 3 MixerMode: "Fixed"
*s Audio Input LocalInput 3 Mute: "Off"
*s Audio Input LocalInput 3 Channels: 2
*s Audio Input LocalInput 3 AGC: "Off"
*s Audio Input LocalInput 3 Connector: "Line.3"
*s Audio Input LocalInput 3 Connector: "Line.4"
*s Audio Input LocalInput 4 Name: "DVD input"
*s Audio Input LocalInput 4 MixerMode: "Fixed"
*s Audio Input LocalInput 4 Mute: "Off"
*s Audio Input LocalInput 4 Channels: 2
