xConfiguration Network [1..1] IPv6 Address
Enter the static IPv6 network address for the system. This setting is only applicable when the
Network IPv6 Assignment is set to Static.
Requires user role: ADMIN
Value space: <S: 0, 64>
Format: A valid IPv6 address.
Example: xConfiguration Network 1 IPv6 Address: "2001:0DB8:0000:0000:0000:0000:0000:000
2"
xConfiguration Network [1..1] IPv6 Gateway
Define the IPv6 network gateway address. This setting is only applicable when the Network IPv6
Assignment is set to Static.
Requires user role: ADMIN
Value space: <S: 0, 64>
Format: A valid IPv6 address.
Example: xConfiguration Network 1 IPv6 Gateway: "2001:0DB8:0000:0000:0000:0000:0000:000
1"
xConfiguration Network [1..1] IPv6 DHCPOptions
Retrieve a set of DHCP options, for example NTP and DNS server addresses, from a DHCPv6
server.
Requires user role: ADMIN
Value space: <Off/On>
Off: Disable the retrieval of DHCP options from a DHCPv6 server.
On: Enable the retrieval of a selected set of DHCP options from a DHCPv6 server.
Example: xConfiguration Network 1 IPv6 DHCPOptions: On
SX20 Codec API Reference Guide TC7.3, OCTOBER 2015.
D14949.13
About the API xConfiguration xConfiguration
xConfiguration Network [1..1] DHCP RequestTFTPServerAddress
xConfiguration Network [1..1] DNS Domain Name
xConfiguration Network [1..1] DNS Server [1..3] Address
46
xCommand
This setting is used only for video systems that are registered to a Cisco Unified Communications
Manager (CUCM).
The setting determines whether the endpoint should ask the DHCP server for DHCP option 150, so
that it can discover the address of the TFTP server (provisioning server) automatically.
If this setting is Off or the DHCP server does not support option 150, the TFTP server address must
be set manually using the Provisioning ExternalManager Address setting.
If the Network VLAN Voice Mode setting is Auto and the Cisco Discovery Protocol (CDP) assigns an
ID to the voice VLAN, then a request for option 150 will always be sent. That is, the Network DHCP
RequestTFTFServerAddress setting will be ignored.
Requires user role: ADMIN
Value space: <Off/On>
Off: The video system will not send a request for DHCP option 150 and the address of the TFTP
server must be set manually. See the note above for any exception to this rule.
On: The video system will send a request for option 150 to the DHCP server so that it can
automatically discover the address of the TFTP server.
Example: xConfiguration Network 1 DHCP RequestTFTPServerAddress: On
DNS Domain Name is the default domain name suffix which is added to unqualified names.
Example: If the DNS Domain Name is "company.com" and the name to lookup is "MyVideoSystem",
this will result in the DNS lookup "MyVideoSystem.company.com".
Requires user role: ADMIN
Value space: <S: 0, 64>
Format: String with a maximum of 64 characters.
Example: xConfiguration Network 1 DNS Domain Name: ""
Define the network addresses for DNS servers. Up to 3 addresses may be specified. If the network
addresses are unknown, contact your administrator or Internet Service Provider.
Requires user role: ADMIN
Value space: <S: 0, 64>
Format: A valid IPv4 address or IPv6 address.
Example: xConfiguration Network 1 DNS Server 1 Address: ""
