Audio status

xStatus Audio

Shows the top level overview of the audio status. The identities of the LocalInput, RemoteInput,
LocalOutput and RemoteOutput are used when querying additional information.

xStatus Audio Microphones Mute

Shows the microphones mute mode.
Value space of the result returned:
<On/Off>
Example:
xStatus Audio Microphones Mute
*s Audio Microphones Mute: Off
** end

xStatus Audio Volume

Shows the volume level (dB) of the loudspeaker output.
Value space of the result returned:
<0..100>
Example:
xStatus Audio Volume
*s Audio Volume: 70
** end

xStatus Audio Input RemoteInput [1..n] CallId

Shows the CallId for the remote audio input.
You can run the command xStatus Audio Input RemoteInput to find the identity [1..n] of the input.
Value space of the result returned:
<0..65534>
Example:
xStatus Audio Input RemoteInput 8 CallId
*s Audio Input RemoteInput 8 CallId: 28
** end
SX20 Codec API Reference Guide TC6.2, JULY 2013.
D14949.04
About the API xConfiguration

xStatus Audio Input Connectors Microphone [1..n] ConnectionStatus

120
xCommand
Indicates whether a microphone is detected on the microphone input connector.
Value space of the result returned:
<NotConnected/HeadsetMicConnected/GenesisConnected/Connected>
Example:
xStatus Audio Input Connectors Microphone ConnectionStatus
*s Audio Input Connectors Microphone 1 ConnectionStatus: NotConnected
*s Audio Input Connectors Microphone 2 ConnectionStatus: Connected
** end
