Starting and Stopping the Measurement

Before starting the measurement, the traffic button in the Application Manager is set to
"green".
Starting the measurement
⇒ Click on the traffic signal button.
– The measurement will be carried out with the parameters, set in the "Measurement
– The traffic button display will change from "green" to "red"
– The status display will change from <Stopped> to <Running>.
– The measurement will be stopped automatically after the Gate time run down.
Stopping a measurement manually
⇒ Click on the traffic signal button again.
The measurement will be stopped.
A-2
"Add & Remove Instruments" dialog after adding the desired virtual instruments
(Preselection: ATM Advanced)
Settings" dialog (Application manager)
A measurement can also be stopped manually.
ANT-20/ANT-20E
Application Guide
