ANT-20/ANT-20E
Toolbar
The toolbar buttons provide direct access to the more important functions of the VI:
• Triggering the Scan function
• Triggering AAL analysis
• Sorting
• Preselecting the interface
• Printing and exporting the results.
Meanings of icons, from left to right (equivalent menu command shown in brackets):
Icon
Table O-3
Operation
Meaning
Start and stop Scan (Scan - Start)
Analyse AAL type in the active channel (Analyse - AAL Type)
Display AAL Type Distribution as a pie chart (Analyse - AAL Type Distribution)
Sort channels by VPI/VCI values (Sort - VPI/VCI)
Sort channels by bandwidth (load) (Sort - Bandwidth)
Delete inactive channels (Options - Aging)
Select UNI (Options - UNI)
Select NNI (Options - NNI)
Print results (Print - Print ...)
Export results (Print - Export ...)
Open on-line help (Help - Contents)
Meanings of icons
Broadband Analyzer/Generator
O-13
