ANT-20/ANT-20E
4.4

Tx/Rx Configuration

The buttons in the "Tx/Rx configuration" field are used to configure the individual protocol layers
for the Tx and Rx sides of the instrument.
The buttons have the following meanings:
Button
SERVICE
SIG
AAL
SAAL
ATM
PHYSICAL
1 Actually not implemented.
2 For Emulate topology with signaling emulation.
3 This button is present for both Tx and Rx for Looped topology. It is only present once for Emulate topology.
Table O-5
Note:
4.4.1

The "ATM Layer" dialog

This sub dialog is used to configure the ATM layer.
a
Fig. O-20
Operation
Meaning
1
Configure the ATM service layer
2
Configure the signaling protocol (Sec. 4.5.1, Page O-21)
1
Configure the ATM adaptation layer
1
Configure the signaling AAL
3
Configure the ATM layer (Sec. 4.4.1, Page O-19)
3
Configure the physical layer (Sec. 4.4.2, Page O-21)
Meaning of action buttons
The most important layer-specific settings are shown on each button area.
Buttons for non-relevant layers are disabled.
c
The "ATM Layer" sub dialog ("Emulate" topology)
Broadband Analyzer/Generator
b
O-19
