ANT-20/ANT-20E
6.3.5

The "Traffic Source" index card

This index card is used to set the default source parameters for the channel.
a
Fig. O-32
The index card contains the following sections:
:
Section
Source type (a)
Forward/Backward Default
Parameters (b)
Additional action buttons for bi-directional asymmetric channels
Forward => Backward
Forward <= Backward
Forward<> Backward
1 Not always available, depends on source type
2 See "General" index card; the buttons only affect the relevant index card
Table O-27
Operation
The "Traffic Source" index card (Channel Editor)
On-Off
Constant bit rate
Peak Cell Rate
Cell Jitter
1
Mean Cell Rate
1
Burst Size
The sections of the "Traffic Source" index card (Channel Editor)
Broadband Analyzer/Generator
b
Meaning
Source type
- On / off source
- Constant bit rate source
Source parameters for forward / backward direction
- Peak cell rate
- Cell delay variation tolerance, referred to the peak cell rate
- Sustainable cell rate
- Burst-tolerance
2
Copies the forward parameters to the backward direction
Copies the backward parameters to the forward direction
Exchanges the forward and backward direction parameters
O-45
