RSV4 R
•
Disconnect the lower injector connec-
tors.
See also
Air box
•
Disconnect the connector.
•
Remove the complete throttle body.

Checking the throttle body

The throttle bodies are maintenance free and are
not serviceable. Replace the entire assembly in
the event of malfunction.
As all the internal components of the throttle body
assembly (potentiometers and electrical motor)
are contactless, no electrical diagnosis is possible.
Functional tests are performed on the throttle body
assembly by the control unit during vehicle oper-
ation, with the results visible on the diagnostic
instrument.
The only action possible before replacing the com-
ponent is checking the connectors and cable har-
nesses.
Power supply
P SUPP - 355
