Engine-Vehicle Connector Pinout Key - APRILIA RSV4 R Service Station Manual

Electrical system
Side stand input PIN 70
Gear input PIN 72
Injection relay control output PIN 73
Upper cylinder 3 injector control output PIN 74
Variable geometry control unit failure input PIN 76 (If available)
"engine stop" input PIN 78
Vehicle speed input PIN 79
CAN H line (high speed) PIN 80
Engine - vehicle connector pinout key:
Key PIN 1A
Vehicle speed PIN 2A
STOP lights relay control output PIN 3A
- PIN 4A
- PIN 5A
- PIN 6A
Analogue ground connection 2 PIN 7A
Direct power supply to control unit PIN 8A
Injection supply PIN 1B
CAN H PIN 2B
CAN L PIN 3B
Key PIN 4A
Electric fan relay control PIN 5B
Fall sensor PIN 6B
Variable geometry power supply PIN 7B
Power ground connection 2 PIN 8B
Injection power supply PIN 1C
Serial line K for diagnosis PIN 2C
Clutch sensor PIN 3C
"Start engine" switch PIN 4C
Start-up control PIN 5C
Injection relay PIN 6C
Engine stop PIN 7C
Power ground connection 2 PIN 8C
