Ease off the side fairing, taking partic-

ular care not to damage the fitting with

the lower side fairing and the tabs fas-

tening the side fairing to the lug.

Release the insert on the retainer with

Release the three inserts on the inner

To refit, repeat the above procedure in reverse order, taking particular care not to damage

the components involved.

HANDLE PAINTED AND PLASTIC COMPONENTS WITH CARE; BE CAREFUL NOT TO SCRATCH

OR DAMAGE THEM.
