Components Arrangement - APRILIA RSV4 R Service Station Manual

Electrical system
pos. Description
1 Upper Silentblock nut, demand sen-
sor mounting bracket
2 Demand sensor fixing screw to
mounting plate

Components arrangement

Key:
ELE SYS - 94
C
ENTRAL ELECTRICAL SYSTEM
Type Quantity
M6 1
SWP 4.9 4
Torque
5 Nm (3.69 lbf ft)
1.2 Nm (0.88 lbf ft)
RSV4 R
Notes
-
-
