Engine
•
Place the thrust plate.
•
Fit the clutch springs.
•
Fit the screw washers.
•
Tighten the six screws operating in
stages and diagonally.

Installing the clutch cover

•
Position the starting transmission gear
on the crankcase.
•
Position the gasket and the two dowel
pins in the clutch cover.
•
Insert the clutch cover, making sure to
have correctly engaged the clutch con-
trol lever and the rack shaft.
•
Screw the sixteen perimetric fixing
screws with the washers.
•
Tighten the screws working in stages
and diagonally.
•
Add engine oil up to the correct level.
