Engine
A slight amount of material may be extracted in the
area shown.

Valve installation

•
Lubricate the valve stem and insert the
valves on the valve guide.
•
Position the springs with the closest
turns facing the head of the valve
CAUTION
THE INTAKE VALVES HAVE A DOUBLE SPRING WHERE-
AS THE EXHAUST VALVES HAVE A SINGLE SPRING.
•
Fit the caps.
ENG - 312
RSV4 R
