EXTRA 330LX
Repeat all the above steps for the other
wing.
INSTALL ELEVATOR CONTROL HORN.
Fiberglass control horn
6
100mm
Instruction Manual.
Elevator fiberglass control horn.
ELEVATOR SERVO INSTALLATION.
1) The elevators have been pre-hinged
and glued to the stabs and are ready for
flight. No other steps are necessary for
hinging.
2) Attach the extension to the servo lead
and secure with Safety Clip, safety wire,
tape or other method. Ensure the plugs
will not come apart from vibration or
light tension.
Epoxy.
Epoxy.
