5) Install servo in servo well with the out-
put arm toward the leading edge of the
wing. Mark and drill location of servo
mounting holes.
Thin CA.
6) Install servo with servo mounting
screws.
38mm
INSTALLING THE AILERON
PUSHROD.
M3x15 Socket Head Cap Screw.
Lock nut.
Lock nut.
M3x15 Socket Head Cap Screw.
Flat washer.
Flat washer.
5
