Use a 1/4 bit to drill the engine mount-
ing holes
Remove mounting template from fire-
wall. Firewall shown with mounting holes
drilled ready for engine mounting.
Using mounting bolts and washers
mount engine to firewall.
Tighten mounting bolts and secure en-
gine to firewall.

THROTTLE SERVO INSTALLATION.

1) Use a 1/4" bit to drill a pushrod exit
hole in the firewall in line with the en-
gine carburetor throttle arm.
2) Assemble ball link to threaded end of
pushrod.
