Seagull Models EXTRA 330LX Assembly Manual page 18

EXTRA 330LX
3) Attach throttle pushrod to the carbu-
retor throttle arm with the ball link.
4) Install adjustable servo connector in
the servo arm as same as picture below:
Loctite secure.
5) Install throttle servo into servo mount-
ing tray.
18
Adjustable servo
connector.
Servo arm.
Instruction Manual.
Thin CA.
6) Reinstall the servo horn by sliding the
connector over the pushrod wire. Center
the throttle stick and trim and install the
servo horn perpendicular to the servo
center line.
Epoxy.
