EXTRA 330LX
BATTERY & RECEIVER.
Install battery using nylon ties and re-
ceiver as shown.
Receiver.
MUFFLER INSTALLATION.
22
1) Gather the materials as shown below.
Battery.
2) Measure and mark the center of the
template material as shown.
3) Measure and mark the center of the
bottom of the fuselage as shown. Mount
cowling to fuse and transfer center line
on fuse to bottom of cowl.
Note: You will use this center mark dur-
ing a later step when aligning template
with cowl.
Instruction Manual.
COWLING.
