Seagull Models EXTRA 330LX Assembly Manual page 13

Attach the steering spring to the rudder
control horn.
Use pliers to twist spring end closed
around rudder control horn.
Do same for attachment the steering
spring to the rudder tiller.
Repeat spring installation for other side.
INSTALLING THE MAIN LANDING
GEAR TO FUSELAGE.
1) The blind nuts for securing the land-
ing gear are already mounted inside the
fuselage.
2) Using the hardware provided, mount
the main landing gear to the fuselage.
3) Place the fuselage inverted on the
workbench in a suitable stand. Set the
landing gear in place and use a screw-
drive to secure the landing gear to the fu-
selage using bolts M4x25mm and wash-
ers. Make sure to use the threadlock on
the bolts so they don't vibrate loose.
