EDGE 540.
3x10mm.
Instruction Manual.
INSTALLING THE SWITCH.
Install the switch into the precut hole in the
servo tray, in the fuselage, from the bottom.
Use the two screws provided with the switch
to secure it in place. Drill two 3/32" holes
through the tray for the screws to pass
through.
INSTALLING THE FUSELAGE SERVO.
Throttle servo.
THROTTLE SERVO INSTALLATION.
) Install adjustable servo connector in the
1
servo arm.
3/ 32" Hole.
Switch.
21
