Figure 2-27. AscTec Navigator Software Flightbook
The map view shows the flight path and photo trigger positions, the list view underneath the map shows: the
log ID (subsequent number), start time and date, the GPS position (WGS84), the number of image tags
(triggers) during the flight, and the flight time. The buttons above the map view allow exporting a single flight
as KML or GPX, or an overview of all flights into a CSV file. It is also possible to export a log file as a ZIP file to
be able to send it by email.
Please see the chapter 5. Flightbook in the AscTec Navigator Software Manual for further details. The manual
can be found here:
It might happen that the Intel Falcon 8+ UAV cannot access a logging storage device.
Mostly, the reason is a mechanical connection issue or a corrupted file system on the
storage device. If the Intel Falcon 8+ UAV cannot access a storage device, a respective
warning will be displayed (see following).
