6.2.4

Flight logs

It might happen that the Intel Falcon 8+ UAV cannot access a logging storage device
(see also
mechanical connection issue or a corrupted file system on the storage device. If the
Intel Falcon 8+ UAV cannot access a storage device, a respective warning will be
displayed:
Table 6-4. Possible warnings
Cause
User SD card
cannot be accessed.
Internal SD card
cannot be accessed.
Note: The Intel Falcon 8+ UAV is able to fly without any active logging device. It is the
responsibility of the user to make sure that all flights can be properly logged if it is a
legal requirement in the country where the system is used.
Neither the USB stick, nor the User SD card will be deleted or formatted by the flight
system. We recommend to regularly make back up copies of these storage devices and
reformat them afterwards. Especially when working on complex projects, during which
the logs are needed for geo-referencing, it is helpful to start with clean storage media.
118
chapter 2.9 Intel Falcon 8+ UAV Flight
Visual signal
appears in the
<- Check Msg
status line of the Status Display.
Push the related arrow LEFT
button on the CTR until the Error
Message Screen is shown.
will be shown.
user SD card
appears in the
<- Check Msg
status line of the Status Display.
Push the related arrow LEFT
button on the CTR until the Error
Message Screen is shown.
internal SD card
shown.
User Manual
Logs). Mostly, the reason is a
Take out the User SD card, make a backup copy
and format it (file system: FAT32, allocation unit
size: 32 kilobytes). After reinserting the SD card
into the Intel Falcon 8+ UAV, it should again be
accessible.
No
If no backup copy is needed, the User SD card can
also be formatted directly by the UAV. To do so:
1. Push ENT to open the menu on the Status
Display.
2. Push the arrow RIGHT button to navigate to
Settings
Push ENT and use the arrow RIGHT button
3.
to navigate to

4. Push ENT to confirm. 
The shown screen appears:

5. Push ENT to confirm the formatting of the
User SD card. 
The process starts, a progress bar is shown.
Pushing ESC cancels the function and brings
you back to the Main Screen.
When the formatting of the SD card is finished, the
Intel Falcon 8+ UAV will immediately create a new
log file and start logging again.
Switch off the Intel Falcon 8+ UAV. Wait 10
seconds and switch it on again. During boot up,
the internal SD card will be formatted and it should
again be accessible. If this does not help, contact
the support to get instructions on how to proceed.
No
will be
Possible fix
.
. 
Format User SD
®
Intel Falcon
TM
F8+
