9. RS-485 Installation and Set-up
9.5.2. Reading a parameter value
Read the value in par. 3-41
PKE = 1155 Hex - Read parameter value in
par. 3-41
IND = 0000 Hex
PWEHIGH = 0000 Hex
PWELOW = 0000 Hex
If the value in par. 3-41
s, the response from the slave to the master
will be:

9.6. Danfoss FC Control Profile

9.6.1. Control Word According to FC Profile (Par. 8-10 = FC profile)
9
Bit
00
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
174
Ramp 1 Up Time.
Ramp 1 Up Time
Ramp 1 Up Time
NOTE
3E8 Hex corresponds to 1000 decimal. The conversion index for par. 3-41 is -2, i.e.,
0.01.
Bit value = 0
Reference value
Reference value
DC brake
Coasting
Quick stop
Hold output frequency
Ramp stop
No function
No function
Ramp 1
Data invalid
No function
No function
Parameter set-up
Parameter set-up
No function
MG.33.B9.22 - VLT
is 10
Bit value = 1
external selection lsb
external selection msb
Ramp
No coasting
Ramp
use ramp
Start
Reset
Jog
Ramp 2
Data valid
Relay 01 active
Relay 02 active
selection lsb
selection msb
Reverse
® is a registered Danfoss trademark.
FC 300 Design Guide
