4. FC 300 Selection
Repeat accuracy of
System response time (terminals 18, 19, 27, 29, 32, 33)
Speed control range (open-loop)
Speed control range (closed-loop)
Speed accuracy (open-loop)
Speed accuracy (closed-loop), depending on resolution of feed-
back device
All control characteristics are based on a 4-pole asynchronous motor
Control card performance:
4
Scan interval
Surroundings:
Enclosure ≤ 10 HP [7.5 kW]
Enclosure ≥ 14.75 HP [11 kW]
Enclosure kit available ≤ 10 HP [7.5 kW]
Vibration test
Max. relative humidity 5%-95% (IEC 60 721-3-3; Class 3K3 (non-condensing) during operation
Aggressive environment (IEC 721-3-3), uncoated
Aggressive environment (IEC 721-3-3), coated
Test method according to IEC 60068-2-43 H2S (10 days)
Ambient temperature
Derating for high ambient temperature, see section on special conditions
Minimum ambient temperature during full-scale operation
Minimum ambient temperature at reduced performance
Temperature during storage/transport
Maximum altitude above sea level
Derating for high altitude, see section on special conditions.
EMC standards, Emission
EMC standards, Im-
munity
See section on special conditions
Control card, USB serial communication:
USB standard
USB plug
Connection to PC is carried out via a standard host/device USB cable.
The USB connection is galvanically isolated from the supply voltage (PELV) and other high-volt-
age terminals.
The USB ground connection is not galvanically isolated from protection ground. Use only an
isolated laptop as PC connection to the USB connector on the adjustable frequency drive.
80
Precise start/stop (terminals 18, 19)
Max. 122°F [50°C] (24-hour average maximum 113°F [45°C])
EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6
MG.33.B9.22 - VLT ® is a registered Danfoss trademark.
≤± 0.1 msec
1:100 of synchronous speed
1:1000 of synchronous speed
30-4000 rpm: error ±8 rpm
0-6000 rpm: error ±0.15 rpm
FC 301: 5 ms / FC 302: 1 ms
IP 20, IP 55
IP 21, IP 55
IP 21/TYPE 1/IP 4X top
0.035 oz [1.0 g] RMS
32° F [0° C]
14° F [-10° C]
-193°-149-158° F [-25°-+65/70° C]
3,280 ft [1,000 m]
EN 61800-3, EN 61000-6-3/4, EN 55011
EN 61800-3, EN 61000-6-1/2,
1.1 (Full speed)
USB type B "device" plug
FC 300 Design Guide
≤ 2 ms
class 3C2
class 3C3
