Case 3: Negative to positive reference with dead band, sign determines the direction,
-Max – +Max
3

3.3.1. Speed PID Control

The table shows the control configurations where speed control is active.
Par. 1-00 Configu-
ration Mode
[0]
loop
[1] Speed closed-
loop
[2] Torque
[3] Process
Note: "N.A." means that the specific mode is not available at all. "Not Active" means that the
specific mode is available but speed control is not active in that mode.
Note: The speed control PID will work under the default parameter setting, but tuning the pa-
rameters is highly recommended in order to optimize motor control performance. The two flux
motor control principles are specially dependant on proper tuning to yield their full potential.
32
Par. 1-01 Motor Control Principle
U/f
Speed open- Not Active
N.A.
N.A.
MG.33.B9.22 - VLT
plus Flux sensorless
VVC
Not Active ACTIVE
ACTIVE N.A.
N.A. N.A.
Not Active ACTIVE
® is a registered Danfoss trademark.
FC 300 Design Guide
Flux w/ enc. feedb
N.A.
ACTIVE
Not Active
ACTIVE
