FC 300 Design Guide
Bits 13/14, Set-up selection
Bits 13 and 14 are used to choose between the
four parameter set-ups according to the fol-
lowing table:
The function is only possible if
has been chosen in par. 0-10
The selection in par. 8-55
mines how bits 13 and 14 are linked with the
corresponding function of the digital inputs.
Changing set-up while running is only possible
if the set-ups have been linked in par. 0-12
This set-up linked to
Bit 15, No function/Reverse
Bit 15 = "0" causes no reversing.
Bit 15 = "1" causes reversing.
Note: In the factory settings, reversing is set to
9.6.6. Status Word according to PROFIdrive Profile (STW)
The status word is used to notify a master
(e.g., a PC) about the status of a slave.
Multi Set-up
Active set-up
Set-up select
deter-
.
NOTE
Bit 15 causes reversing only when
selected.
MG.33.B9.22 - VLT ® is a registered Danfoss trademark.
9. RS-485 Installation and Set-up
Set-up Bit 13
1 0
2 1
3 0
4 1
.
digital Reversing select
in par. 8-54
Ser. communication, Logic or
Bit Bit = 0
00 Control not
ready
01 Drive not
ready
02 Coasting
03 No error
04 OFF 2
05 OFF 3
06 Start possible Start not possible
07 No warning
Speed ≠ refer-
08
ence
09 Local opera-
tion
10 Out of fre-
quency limit
11 No operation
12 Drive OK
13 Voltage OK
14 Torque OK
15 Timer OK
Bit 14
0
0
1
1
.
or Logic and is
Bit = 1
Control ready
Drive ready
Enable
Trip
ON 2
ON 3
Warning
Speed = reference
Bus control
Frequency limit ok
In operation
Stopped, autostart
Voltage exceeded
Torque exceeded
Timer exceeded
