Gain
Command format: SET●/MEDIA/AUDIO/<I
Response format: pw●/MEDIA/AUDIO/<I
Parameters:
Example:
˃ SET /MEDIA/AUDIO/I5.Gain=3
˂ pw /MEDIA/AUDIO/I5.Balance=3

8.7. RS-232 port configuration

8.7.1. Protocol setting
Command format: SET●/MEDIA/UART/<P
Response format: pw●/MEDIA/UART/<P
Parameters:
.ControlProtocol
RS-232 protocol mode
Example:
˃ SET /MEDIA/UART/P2.ControlProtocol=1
˂ pw /MEDIA/UART/P2.ControlProtocol=1
8.7.2. BAUD rate setting
Command format: SET●/MEDIA/UART/<P
Response format: pw●/MEDIA/UART/<P
Parameters:
BAUD rate value
Example:
˃ SET /MEDIA/UART/P2.Baudrate=2
˂ pw /MEDIA/UART/P2.Baudrate=2
8.7.3. Databit setting
Command format: SET●/MEDIA/UART/<P
Response format: pw●/MEDIA/UART/<P
Example:
˃ SET /MEDIA/UART/P2.DataBits=8
˂ pw /MEDIA/UART/P2.DataBits=8
Page 80 / 106
<level> Sets the input gain between -9 dB and 6 dB in step of 3 dB. The
value is rounded down if necessary to match the step value.
.Baudrate 0
4800
>.Gain=<level>
n
>.Gain=<level>
n
>.ControlProtocol=0|1
n
>.ControlProtocol=0|1
n
0 1
LW2 LW3
>.Baudrate=0|1|2|3|4|5|6|7
n
>.Baudrate=0|1|2|3|4|5|6|7
n
1 2 3
7200 9600 14400
>.DataBits=8|9
n
>.DataBits=8|9
n
4 5 6
19200 38400 57600
LW3 programmers' reference
7
115200
