INFO
In this case, the outputs are linked; the change will affect both local and fiber optical output
ports.
INFO
The audio priorities can be queried by typing the "prio_a<out>=?" command.
7.3.12. Batch switch outputs
Description: The device is capable of switching multiple outputs exactly at the same time.
To do this, the normal switch commands have to be used. If the switch commands arrive at
the device with less than 10 milliseconds delay, the commands are collected and changes
the output connections together. Required circumstances:
▪
▪
▪
▪
If any of the above circumstances fail, then the commands will be processed separately.
INFO
The delay timeout applies for the receiving time of characters. Please note that if LAN
connection is used then the network may cause additional delays. This could result that
batch switching does not occur.
The below example shows a command that resulted batch switching:
 {2@1 V}CrLf
 (O01 I02 V)CrLf
 (O01 I02 A)CrLf
 (O02 I02 V)CrLf
 (O02 I02 A)CrLf
 {5@1 A}CrLf
 (O01 I05 A)CrLf
 (O02 I05 A)CrLf
Page 56 / 106
Switch commands have this format: {<in>@<out>}{<in>@<out>}
The delay between two '}' characters must be below 10 milliseconds.
No other command or junk character is allowed between switch commands.
Affected outputs must be unlocked.
One by one commands Batch commands
 {02@01 V}{05@01 A}CrLf
 (O01 I02 V)CrLf
 (O01 I02 A)CrLf
 (O02 I02 V)CrLf
 (O02 I02 A)CrLf
 (O01 I05 A)CrLf
 (O01 I05 A)CrLf
