11.4. Maximum fiber cable extensions
1080p@60Hz 24 bpp
1080p@60Hz 36 bpp
4096x2048@30Hz 24 bpp
11.5. Content of backup file
The backup file contains numerous settings and parameters saved from the device. When
the file is uploaded to a device, the followings will be overwritten:
RS-232 mode, Control protocol, Baud rate, Data bits, Stop bits, Parity
Port name and CI (Command Injection) port number
Video port name, Audio port name, HDCP setting
Video port name, Audio port name, HDCP setting
Video port name, Audio port name, HDCP setting
Volume, Balance, Gain, Port name
Audio autoselect settings, Mute ports, Lock ports, Switch ports
Video autoselect settings, Mute ports, Lock ports, Switch ports
Video port name, Audio port name
Test pattern mode, clock source, and type
HDCP mode, HDMI mode
RS-232 mode, Control protocol, CI port number, Port name
Remote port name, Enabled/Disabled setting
Port name, HDCP mode, HDMI mode, Power +5V mode
Test pattern mode, clock source, and type
DHCP status (enable / disable)
Static IP address, Network mask, Gateway address
GPIO port names, directions (input/output), and levels (high/low)
User EDID data (U1-U14)
Event manager: settings of all Events (1-20)
Appendix
OM1 OM2
(62.5/125) (50/125)
250 m 600 m
150 m 400 m
Not supported 350 m
Local serial port
HDMI input port(s)
DP input port
DVI-D input port
Analog audio input ports
Crosspoint settings
Optical output port
Local output port
Network settings
Further settings
HDMI-3D-OPT-TX200 series
User's manual
OM3 OM4
(50/125) (50/125)
1200 m 2500 m
800 m 1300 m
700 m 1100 m
