8.5.19. HDMI mode settings (output ports)
Command format: SET●/MEDIA/VIDEO/<O
Response format: pw●/MEDIA/VIDEO/<O
Parameters:
.HdmiModeSetting
Example:
˃ SET /MEDIA/VIDEO/O1.HdmiModeSetting=2
˂ pw / MEDIA/VIDEO/O1.HdmiModeSetting=2
8.6. Audio port settings
INFO
The settings described in the coming sections depend on the device as the input port
numbers are different. Port numbers are listed in section
8.6.1. Analog audio input level settings
INFO
The following settings are valid only for analog audio input ports.
Volume
Command format: SET●/MEDIA/AUDIO/<I
Response format: pw●/MEDIA/AUDIO/<I
Parameters:
Example:
˃ SET /MEDIA/AUDIO/I5.Volume=-15
˂ pw /MEDIA/AUDIO/I5.Volume=-15.000
Balance
Command format: SET●/MEDIA/AUDIO/<I
Response format: pw●/MEDIA/AUDIO/<I
Parameters:
Example:
˃ SET /MEDIA/AUDIO/I5.Balance=0
˂ pw /MEDIA/AUDIO/I5.Balance=0
LW3 programmers' reference
HDMI mode Auto
<level> Sets the input volume (attenuation) between -95.625 dB and 0 dB
in step of -0.375 dB. The value is rounded up if necessary to match
with the step value.
<level> Sets the balance; 0 means left balance, 100 means right balance,
step is 1. Center is 50 (default).
>.HdmiModeSetting=0|1|2
n
>.HdmiModeSetting=0|1|2
n
0 1
HDMI
>.Volume=<level>
n
>.Volume=<level>
n
>.Balance=<level>
n
>.Balance=<level>
n
HDMI-3D-OPT-TX200 series
User's manual
2
DVI
11.2 on page 101.
Page 79 / 106
