Audio and Video LEDs
The input ports have their own LEDs regarding the Audio and/or Video state. The functions
of these LEDs are the same and refer to the given input port.
Audio LEDs
Video LEDs
USB LED
INFO
When Autoselect is enabled and video signal is not present at all, video LEDs blink.
Installation and controls
dark: the audio source is not selected.
blinks:
the audio source is selected but no signal is detected, regardless of
the output mode (e.g. DVI EDID is emulated on the port with HDMI
signal).
lights: (with short pause): audio source is selected, the port is active but
audio is not embedded in the video stream (e.g. the output mode is
DVI).
(continuously): audio source is selected, the audio is embedded to
the output video stream.
dark: the video source is not selected.
(only in case of SW4-OPT-TX240RAK model)
blinks: the video source is selected but signal is not detected.
lights: the video source is selected and signal is detected.
dark: USB is disconnected.
lights (yellow): Connection is established between the transmitter and the
computer.
