11.6. Factory default settings
HDCP (DP, HDMI, DVI-D)
No sync screen mode
No sync screen clock source
No sync screen pattern
Output laser enabled
Output HDMI mode
Output HDCP mode
Power 5V mode
Selected video on optical output
Autoselect mode
Autoselect video priority
(SW4-OPT-TX240RAK)
Volume (analog audio)
Balance (analog audio)
Gain (analog audio)
Selected audio on optical output
Autoselect audio priority
(SW4-OPT-TX240RAK)
DP input
HDMI input
DVI-D input
IP address
Subnet mask
Static gateway
DHCP
LW2 Port number
LW3 Port number
HTTP Port number
Control protocol
Baud rate
Databits
Parity
Stopbits
Operation mode (Local and Local)
Command injection port nr. (Local)
Command injection port nr. (Link)
GPIO direction
GPIO output level
Page 104 / 106
Parameter
Video port settings
Audio port settings
Emulated EDIDs
Network settings (SW4-OPT-TX240RAK)
RS-232 and GPIO settings
Setting/Value
Enabled
Disabled
480p
Bar
On
Auto
Auto
Always on
I1 input port
Disabled, Priority detect, No change
0=DP, 1=HDMI, 2=HDMI2, 3=DVI-D
0.00 dB
50 (center)
0 dB
I1 input port
0=DP, 1=HDMI1, 2=HDMI2, 3=DVI-D, 4=Analog1
in, 5=Analog2 in
D1 – Dynamic EDID
D1 – Dynamic EDID
D1 – Dynamic EDID
192.168.0.100
255.255.255.0
192.168.0.1
Disabled
10001
6107
80
LW2
57600
8
No
1
Pass-through
8001
8002
Input
High
