8.7.4. Stopbits setting
Command format: SET●/MEDIA/UART/<P
Response format: pw●/MEDIA/UART/<P
Parameters:
Example:
˃ SET /MEDIA/UART/P2.StopBits=0
˂ pw /MEDIA/UART/P2.StopBits=0
8.7.5. Parity setting
Command format: SET●/MEDIA/UART/<P
Response format: pw●/MEDIA/UART/<P
Parameters:
Example:
˃ SET /MEDIA/UART/P2.Parity=0
˂ pw /MEDIA/UART/P2.Parity=0
8.7.6. RS-232 operation mode
Command format: SET●/MEDIA/UART/<P
Response format: pw●/MEDIA/UART/<P
Parameters:
RS-232 operation mode
Example:
˃ SET /MEDIA/UART/P2.Rs232Mode=1
˂ pw /MEDIA/UART/P2.Rs232Mode=1
Command injection mode
Command format: SET●/MEDIA/UART/<P
Response format: pw●/MEDIA/UART/<P
Example:
˃ SET /MEDIA/UART/P2.CommandInjectionEnable=true
˂ pw /MEDIA/UART/P2.CommandInjectionEnable=true
ATTENTION!
The Command injection status is stored in another read-only property:
/MEDIA/UART/<P
LW3 programmers' reference
.StopBits
Stopbit value
.Parity
Parity setting no parity
.Rs232Mode
Pass-through
>.CommandInjectionStatus.
n
>.StopBits=0|1|2
n
>.StopBits=0|1|2
n
0 1
1 1,5
>.Parity=0|1|2
n
>.Parity=0|1|2
n
0 1
odd
>.Rs232Mode=0|1|2
n
>.Rs232Mode=0|1|2
n
0 1
Control
>.CommandInjectionEnable=true|false
n
>.CommandInjectionEnable=true|false
n
HDMI-3D-OPT-TX200 series
User's manual
2
2
2
even
2
Command injection
