11.3. Mechanical drawings
SW4-OPT-TX240RAK can be seen in the pictures but the dimensions are valid for all the
models. Dimensions are in mm.
Bottom view
Front view
HDCP
Top view
Multi input Multimode Fiber Transmitter
with local monitor out
Single Fiber Technology
HDMI, 3D, 4K supported
Bi-directional RS-232
USB KVM
VIDEO SELECT:
AUDIO SELECT:
INPUT STATUS LED FUNCTIONS
Blinking: Selected input has no signal
Continuous ON: Signal present on active input
Rear view
LASER APERTURE
Side view
Page 102 / 106
M3 thread
VIDEO AUDIO VIDEO AUDIO
USB
1 DP IN 2 HDMI1 IN
( )
HID extension
HDMI 1 HDMI 2
DP
Autoselect DVI-D
Video embedded Audio 1
No Audio Audio 2
SC MM
6 AUDIO2 IN
OUTPUT
L R HDMI OUT
178.5
VIDEO AUDIO
3 HDMI2 IN 4 DVI-D IN
221
Rear LED functions
LIVE
OFF: No power
Green blinking (1 sec): Normal operation
Red blinking (1 sec): Alert
Yellow blinking (0.5 sec): Firmware upgrade mode
Yellow continuous: Powered but no operation
Laser Active:
ON: Laser output enabled
Fiber Link:
Blinking: Waiting for RX
ON: RX detected
RS-232
OFF: Pass-through mode
Blinking: Command injection mode
ON: Control mode
LIVE
LASER ACTIVE
FIBER LINK
RS-232
ETHERNET
M3 thread
VIDEO AUDIO1 Autoselect AUDIO2
AUDIO
RST
VIDEO AUDIO SHOW
5 AUDIO1 IN SELECT SELECT
SW4-OPT-TX240RAK
Port legend
Audio only
1 Video with embedded audio
INVISIBLE LASER RADIATION
AVOID DIRECT EYE EXPOSURE
CLASS 3R LASER PRODUCT
OUTPUT POWER <= 5mW
CLASSIFIED BY: EN 60825-1:2014
RADIATED WAVELENGTHS:
778nm, 800nm, 825nm, 850nm, 911nm
T o reload factory defaults:
press Show Me for 10 seconds then quickly 3x
For best performance use OM3e or OM4 fiber cable
Sn: RoHS
Made in EU, Hungary
PIN: 2.35mm
GPIO RS-232
1 2 3 4 5 6 7 TX RX 5V DC 1A
20
ME
