4.2.5
Prepare the pump rinsing system
Illustration of the pump piston
rinsing systems
Part
1
2
3
4
ÄKTA avant Operating Instructions 29101556 AB
Description
Inlet tubing to the sample pump piston rinsing system
Outlet tubing from the sample pump piston rinsing system
Inlet tubing to the system pump piston rinsing system
Outlet tubing from the system pump piston rinsing system
4.2 Hardware installation
4.2.5 Prepare the pump rinsing system
4 Installation
77
