Broadcom NetXtreme Ethernet Adapter • Diagnostic User's Guide

11 ERROR MESSAGES

ERROR ID ERROR NO.
NO_ERROR
ERR_IND_REG_ERR
ERR_CHIP_RUNNING
ERR_BAD_NIC
ERR_READ_ONLY_CLEAR
ERR_READ_ONLY_SET
ERR_READ_WRITE_NOT_CLEAR
ERR_READ_WRITE_NOT_SET
ERR_BIST
ERR_INTERRUPT
CMD_ABORT
ERR_DMA_TXDATA
ERR_DMA_RXDATA
ERR_TXDMA
ERR_RXDMA
ERR_MEM
ERR_MEM2
ERR_EEP_WRITE
ERR_EEP_READ
ERR_EEP_DATA
ERR_FILE_OPEN
ERR_BAD_CPU_CFG
ERR_IMAGE_SIZE
ERR_MALLOC
ERR_CPU_RESET
ERR_CPU_NO_RESP
ERR_CPU_TEST
ERR_DMA_RANGE
ERR_DMA_DATA
ERR_PHY_ID
ERR_PHY_TOO_MANY_REG
ERR_VPD_WRITE
ERR_VPD_DATA
ERR_NO_LINK
ERR_DATA_TX
ERR_DATA_TX_MISSING
ERR_DATA_RX_MISSING
ERR_INVALID_TEST
ERR_EEPROM_CHECKSUM
ERR_READING_WOL_PXE
ERR_READING_WOL_PXE
ERR_NO_EXT_SRAM
ERR_DMA_LEN
ERR_FILE_TOO_BIG
ERR_INVALID
ERR_WRITE
CMD_QUIT
ERR_CPU_MEM_ERR
ERR_ENDIF
ERR_ROM_D_DATA
ERR_CHIP_NOT_RUNNING
ERR_NO_REG_DEF
ERR_ASF_RST
ERR_ASF_ATTN_LOC
ERR_ASF_RST_VAL
ERR_ASF_PA_TIMER
ERR_ASF_PA_CLEAR
ERR_ADF_NO_STAMP
ERR_ADF_NO_TIMER
ERR_ASF_EVENT
ERR_EEP_FILESIZE
ERR_MAGIC_VALUE
ERROR STRING
0
1 Got XXXX @ XXXX. Expected XXXX
2 Cannot perform task while chip is running
3 Invalid NIC device
4 Read only bit X got changed after writing zero at offset XXXX.
5 Read only bit X got changed after writing one at offset XXXX
6 R/W bit X did not get cleared after writing zero at offset
XXXX
7 R/W bit X did not get set after writing one at offset XXXX
8 BIST failed
9 Could not generate interrupt
10 Aborted by user
11 Tx DMA:Got XXXX @ XXXX. Expected XXXX
12 Rx DMA:Got XXXX @ XXXX. Expected XXXX
13 Tx DMA failed
14 Rx DMA failed
15 Data error, got XXXX at XXXX, expected XXXX
16 Second read error, got XXXX at XXXX, expected XXXX
17 Failed writing NVRAM at XXXX
18 Failed reading NVRAM at XXXX
19 NVRAM data error, got XXXX at XXXX, expected XXXX
20 Cannot open file <filename>
21 Invalid CPU image file <filename>
22 Invalid CPU image size XXXX
23 Cannot allocate memory for size XXXX
24 Cannot reset Rx | Tx CPU
25 Rx | Tx CPU does not respond
26 Rx | Tx CPU test failed
27 Invalid Test Address Range
Valid NIC address is XXXX- and exclude XXXX-XXXX
28 DMA:Got XXXX @ XXXX. Expected XXXX
SRAM data=XXXX @ XXXX
29 Unsupported PhyId XXXX:XXXX
30 Too many registers specified in the file, max is XXXX
31 Cannot write to VPD address XXXX
32 VPD data error, got XXXX @ XXXX, expected XXXX
33 No good link! Check Loopback plug
34 Cannot TX Packet!
35 Requested to Tx XXXX. Only XXXX is transmitted
36 Expected XXXX packets. Only XXXX good packet(s) have been
received.
XXXX unknown packets have been received.
XXXX packets have been missing.
37 XXXX is an invalid Test
38 NVRAM checksum error
39 Error in reading WOL/PXE
40 Error in writing WOL/PXE
41 No external memory detected
42 DMA buffer XXXX is too large, size must be less than XXXX
43 File size XXXX is too big, available space is XXXX
44 Invalid <string>
45 Failed writing XXXX to XXXX
46
47 Rx | Tx CPU access error @ XXXX, expected XXXX but got XXXX
48
49 ROM disable error, data returned while disabled
50 Cannot perform task while chip is not running. (need driver)
51 Cannot open register define file or content is bad
52 ASF Reset bit did not self-cleared
53 ATTN_LOC XXXX cannot be mapped to Rx | Tx CPU event bit XXXX
54 Register is not cleared to zero after reset
55 Cannot start poll_ASF Timer
56 poll_ASF bit did not get reset after acknowleged
57 Timestamp Counter is not counding
58 Timer is not working
59 Cannot clear bit X in Rx | Tx CPU event register
60 Invalid file size, expected XXXX but only can read
XXXX bytes
61 Invalid magic value in XXXX, expected XXXX but found XXXX
