Broadcom NetXtreme Ethernet Adapter • Diagnostic User's Guide
PageUP/PageDN to scroll. Ins/Del toggles refresh. ESC to exit

10.79 ringIndex

Command:
Description: Dump Ring Index. Load Mac driver before running.
Syntax: ringindex t | r
Options:
-n<DEC>
-r
-t
Example:
1 Load MAC dirver and display TX and RX Ring Index.
0:> loaddrv
Bus Number
Device/Funtion
Base Address
IRQ
Bringing up MAC driver ... OK
PHY calculated ID: 60008162
BCM5702/03 Internal Phy Rev#2
Configuring BCM54xx ... Done
Determining Link Speed ... 1000Base-T Full Duplex
0:> ringindex rt
RxStdPidx
RxStdCidx
RetRPidx#00
RetRCidx#00
SendHostPidx#00
SendHostCidx#00
SendHostPidx#01
SendHostCidx#01
SendHostPidx#02
SendHostCidx#02
SendHostPidx#03
SendHostCidx#03

10.80 phyctrl

Command: phyctrl
Number of Rx Ring to dump (Default=1) (def=1)
Dump Rx Ring Index
Dump Tx Ring Index
: 1
: 11/0
: 0xfb010000
: 9
Mailbox RBDI
======= ====== ====== ====== =======
100 100
--- ---
--- ---
000 ---
Mailbox SBDI SBDSEL
======= ====== ====== ====== =======
000 000
--- ---
000 000
--- ---
000 000
--- ---
000 000
--- ---
page 119
Broadcom Confidential and Proprietary
RBDC HC StsBlk
100 --- ---
--- 000 000
--- 000 ---
--- --- ---
HC StsBlk
--- --- ---
000 000 000
--- --- ---
000 000 000
--- --- ---
000 000 000
--- --- ---
000 000 000
Driver
======
100
000
---
000
Driver
======
000
000
000
000
000
000
000
000
