Broadcom NetXtreme Ethernet Adapter • Diagnostic User's Guide
70
Memory Stick INS Polarity
Description:
Configure Memory Stick INS Polarity.
Active High (0) Active High
Active Low (1) Active Low
71
Memory Stick INS Chip Pull-up/Pull-down Override
Description:
Configure Memory Stick INS internal Chip Pull-up/Pull-down override.
Disable (0)
Activate Pull-up and
deactivate Pull-down (1)
Activate Pull-down and
deactivate Pull-up (2)
Deactivate Pull-up and
Pull-down (3)
72
SD/MMC Card Detect Internal Chip Pull-up/Pull-down Override
Description:
Configure SD/MMC Card Detect internal Chip Pull-up/Pull-down Override.
Disable (0)
Activate Pull-up and
deactivate Pull-down (1)
Activate Pull-down and
deactivate Pull-up (2)
Deactivate Pull-up and
Pull-down (3)
73
SD Write Protect Internal Chip Pull-up/Pull-down Override
Description:
Configure SD Write Protect Internal Chip Pull-up/Pull-down Override.
Disable (0)
Activate Pull-up and
deactivate Pull-down (1)
Activate Pull-down and
deactivate Pull-up (2)
Deactivate Pull-up and
Pull-down (3)
74
xD Picture Card Detect Polarity
Description:
Configure xD Picture Card Detect Polarity.
Active Low (0) Active Low
Active High (1) Active High
75
xD Picture Card Detect Internal Chip Pull-up/Pull-down Override
Description:
Configure xD Picture Card Detect Internal Chip Pull-up/Pull-down Override.
Disable (0)
Broadcom Confidential and Proprietary
Disable override
Activate Pull-up and deactivate Pull-down
Activate Pull-down and deactivate Pull-up
Deactivate Pull-up and Pull-down
Disable override
Activate Pull-up and deactivate Pull-down
Activate Pull-down and deactivate Pull-up
Deactivate Pull-up and Pull-down
Disable override
Activate Pull-up and deactivate Pull-down
Activate Pull-down and deactivate Pull-up
Deactivate Pull-up and Pull-down
Disable override
