Broadcom NetXtreme User Manual page 188

Broadcom NetXtreme Ethernet Adapter • Diagnostic User's Guide
ERR_SADB_ENTRY
ERR_SADB_CORRUPT
ERR_SADB_DEL_ALL
ERR_SADB_DEL
ERR_SADB_INTR
ERR_SADB_ENTRY_TEST
ERR_SHA1_NOT_SUPPORTED
ERR_DIR_CHECKSUM,
ERR_APE_REGISTER_RANGE,
ERR_APE_MUTEX_RELEASE,
ERR_APE_MUTEX_REQUEST_GRANT 205 APE Mutex register was not granted (Mutex registers
ERR_APE_TIMER_RESET
ERR_APE_TIMER_RUN
ERR_APECPU_LOAD
ERR_APECPU_TIMEOUT
ERR_APECPU_MEM
ERR_APECPU_ETH
ERR_APECPU_SMB
ERR_APECPU_GPIO
ERR_APECPU_EVENT
ERR_APECPU_MUTEX
ERR_APECPU_TIMER
ERR_APECPU_GRC
ERR_POST_100_LB
ERR_DATA_TX_MISSING_IPSEC
ERR_DATA_RX_MISSING_IPSEC
ERR_RX_HW_CRYPTO_DONE_CNT
ERR_USER_BLOCK_NOT_AVAILABLE 222 User block not available
ERR_CPU_MUTEX_ERROR
ERR_CPU_REG_ERROR
ERR_CPU_BIN_FILE_MISMATCH
ERR_USB_NOT_DETECTED
ERR_USB_DATA_ERROR
ERR_SELFBOOTII_BAD_ECC,
ERR_SELFBOOTII_BAD_CPD,
ERR_SELFBOOTII_FULL,
ERR_SELFBOOTII_EMPTY,
ERR_SELFBOOTII_OTP_CORRUPTED 232 Dismatched when compared to file <filename>
195 SADB Entry error at SA Indx XXXX with pattern <string>
196 SADB Data corrupted: Got XXXX at SADB index XXXX word index
XXXX. Expected = XXXX
197 SADB delete all error
198 SADB delete SA index XXXX error
199 SADB interrupt not set. <string> index XXXX
200 SADB Entry Test error at SA Indx XXXX
201 SHA1 not supported
202 Directory Checksum Error
203 Invalid APE register range
204 Can not release APE Mutex Grant register
0xXXXX=XXXX; 0xXXXX=XXXX).
206 APE Timer reset value error, XXXX.
207 APE Timer counting error, XXXX.
208 APE firmware load error: XXXX
209 APE CPU test timed out: XXXX
210 APE CPU Memory Test error: XXXX
211 APE CPU Ethernet Test error: XXXX
212 APE CPU SMBus Test error: XXXX
213 APE CPU GPIO Test error: XXXX
214 APE CPU Event Test error: XXXX
215 APE CPU Mutex Test error: XXXX
216 APE CPU Timer Test error: XXXX
217 APE CPU GRC Test error: XXXX
218 Tx/Rx Lines Have A Short/Open
219 Requested Tx of XXXX IPSEC Pkt(s) with Cipher <string>.
Only XXXX transmitted
220 Expected Rx of XXXX IPSEC Pkt(s) with Cipher <string>.
Only XXXX received
221 Got HW_CRYPTO_DONE_CNT = XXXX, Expected XXXX
223 Rx | Tx CPU test APE Mutex error, test XXXX
224 Rx | Tx CPU test APE reg error, test XXXX
225 Soledad Rev B0 and up should use cpusd.bin version 4.0 or
up.
226 USB device was not detected.
connection.
227 USB device error during data transfer.
228 SelfbootII CPD #XXXX ECC got corrupted.
229 SelfbootII CPD #XXXX got corrupted.
230 OTP is full.
231 OTP is empty.
page 188
Broadcom Confidential and Proprietary
Please check cable
