Mft II. Chksum : 0xad87f388 (0x88f387ad)
*******************************************************
Example: (For Boot Code).
The following menu could be different from yours.
1. Program Serial EEPROM with defaults value and set verbose level to 0.
0:> secfg
Reading current NVRAM ... OK
Validating content...
1. MAC Address
2. Power Dissipated (D3:D2:D1:D0)
3. Power Consumed (D3:D2:D1:D0)
4. Vendor ID
5. Vendor Device ID
6. Subsystem Vendor ID
7. Subsystem Device ID
8. PXE (does not apply to PXE in system ROM)
9. PXE Link Speed { Auto(0),10HD(1),10FD(2)
10. Magic Packet WoL { Enable(1), Disable(2) }
11. Product Name : Broadcom NetXtreme Gigabit Ethernet Controller
12. Part Number
13. Engineering Change
14. Serial Number
15. Manufacturing ID
16. Asset Tag
17. Part Revision
18. Voltage { 1.3V(0), 1.8V(1) }
19. Force PCI Mode { Enable(1),Disable(2) }
20. PHY Type { Copper(1),Fiber(2) }
21. Led Mode { Mac Mode(0), Phy Mode1 (1), Phy Mode2 (2),
Shasta Mac Mode (3), SharedTraffic (4),
Wireless Combo (5)}
22. PHY ID ([PHY#2][PHY#3])
23. Max PCI Retry {0-7, 8=auto}
24. Advanced firmware feature (ASF/IPMI/UMP)
25. Dual MAC mode {Normal(0), MAC_B only(1)
MAC_A only(2), XBAR(3), swap(4), swapXBAR(7)}: 0
26. MBA Boot Protocol {PXE(0), RPL(1), BOOTP(2),
27. MBA Bootstrap Type
{Auto(0), BBS(1), Int18(2), Int19(3)}: 0
28. MBA Delay Time (0-15)
29. Expansion ROM size (does not apply to PXE in system ROM)
{ 64k(0), 128k(1), 256k(2),512k(3), 1M(4), 2M(5),
30. Design Type: {NIC(0), LOM(1)}
31. Read only VPD Vendor Specific Data (V0)
32. Read/Write VPD Vendor Specific Data (V1)
33. Reversed Nway {No(0), Yes(1)}
34. Limit WoL Speed to 10 {No(0), Yes(1)}
35. Fiber WoL Capable {No(0), Yes(1)}
36. Clock-Run Setting {Disable(0), Enable(1)}
37. Enable PHY Auto Powerdown {No(0), Yes(1)}
38. Disable PowerSaving capability {No(0),Yes(1)}: No
Broadcom Confidential and Proprietary
{ Enable(1), Disable(2) }
100HD(3),100FD(4) } : Auto
{ Enable(1), Disable(2) }
iSCSI(3)} : 0
4M(6), 8M(7), 16M(8) } : 0
page 61
: 00:10:18:04:1a:36
: 10:0:0:100
: 10:0:0:100
: 14E4
: 1653
: 14E4
: 1653
: Disable
: Disable
: BCM95705A50
: 106679-15
: 0123456789
: 14e4
: XYZ01234567
: A0
: 1.8V
: Disable
: Copper
: Phy Mode1
: 00206160
: 8
: Disable
: 0
: NIC
:
:
: No
: No
: No
: Disable
: No
