Broadcom NetXtreme Ethernet Adapter • Diagnostic User's Guide
$::nx1(FW_TYPE) – the type of the firmware residing in the selected device (e.g. "BC",
•
"HWSB" , "SB" or "SBII")
$::nx1(FW_VER) – the version of the firmware residing in the selected device (e.g.
•
"1.36")
$::nx1(IRQ) – the IRQ number for the selected device (e.g. 10)
•
$::nx1(MAC_ADDR) – the MAC address of the selected device (e.g. "001018010B23")
•
$::nx1(MAX_SPEED) – the maximum data rate of the selected device (e.g. 1000)
•
$::nx1(MBA) – an indicator of whether or not MBA is installed and enabled on the
•
selected device (e.g. 1
$::nx1(MBA_SPEED) – the speed of MBA (e.g. "auto", "10 HD", etc.)
•
$::nx1(MBA_VER) – the version of MBA image installed on the device (e.g. "1.1.2").
•
$::nx1(NVM_SIZE) – the flash size on the selected device (e.g. 135168).
•
$::nx1(NVM_TYPE) – the type of flash on the selected device (e.g. BUFFERED).
•
$::nx1(BOARD) – the board number of the selected device (e.g. 5718)
•
$::nx1(PHY_TYPE) – the PHY medium type of the device (e.g. "COPPER",
•
"SERDES")
$::nx1(PORT) – indicates the port index of the multi-port device (e.g. 0
•
port 1, 2 port 2, 3
$::nx1(PORT_CNT) – the number of ports of the selected device (e.g. 2)
•
$::nx1(SSID) – the PCI subsystem ID of the device (e.g. 0x164a)
•
$::nx1(SVID) – the PCI subsystem vendor ID of the device (e.g. 0x14e4)
•
$::nx1(VID) – the PCI vendor ID of the device (e.g. 0x14e4)
•
$::nx1(DID) – the PCI device ID (e.g. 0x16B4)
•
$::nx1(TOTAL_DEV) – total number of NX1 devices (e.g. 3)
•
$::nx1(MFW) – an indicator of whether management firmware is installed and enabled
•
on the selected device (e.g. 1
$::nx1(ASF_VER) – the version of the IPMI firmware residing in the selected device
•
(e.g. "7.1.2")
Broadcom Confidential and Proprietary
enabled)
port 3)
enabled).
page 191
port 0, 1
